drylin®: Online Tools

Expert for lead screw units

Find and calculate suitable lead screw units

Configurator for lead screw units

Configure required dimensions

drylin® lead screw modules expert
The selection refers to various lead screw and nut materials, whose suitability for the application and the expected service life are calculated.

drylin® lead screw configurator
Quickly and easily request lead screw nuts and lead screws in individual required dimensions.


Linear module designer

Complete drive systems can be configured

Linear module designer
The designer for drylin® linear modules now allows the determination of corresponding motors and other accessories in addition to calculating suitable linear units. Find the right linear module, including CAD data and a parts list, in just a few clicks. Order or submit an enquiry online.
To the linear module designer

drylin® SHT drive technology configurator

Configure the complete drylin® SHT lead screw module

With the new drylin® SHT drive technology configurator, you can quickly and easily configure your individual drylin® SHT lead screw module.

Expert for linear plain bearings

System selection & service life calculation with CAD

CAD configurator for linear systems

Quickly generate complete 3D models

drylin® expert
In addition to calculating the correct linear unit, the product finder for drylin® drive technology also provides the option to calculate the correct motors, incl. service life.

CAD configurator for linear systems
Creation of complete system with several guide carriages and rails in different installation positions.


drylin® E product finder for motors

Find the right motor in only a few steps

With the expert, you will find the right drylin® E motor for your application with just a few clicks. Simply use the online tool to enter your desired criteria, whether with Hall, encoder or by entering the required flange size, and place the product directly into your shopping cart.
To the product finder
